dur-solo
Metal Ceiling Clouds
dur-solo clouds are crafted from perforated galvanized steel, aluminum, or stainless steel, providing floating rafts of sound absorption. They come in various finishes like powder-coated, anodized, or mirror polished, and can even be digitally printed. You can choose from a range of standard or custom perforation patterns. Additionally, clouds can be made using expanded metal mesh.
Cloud ceilings serve as a fantastic way to break the monotony of a ceiling’s visual appearance. They offer flexibility for incorporating and accessing HVAC, sprinklers, and lighting systems. Clouds are particularly suitable for radiant or chilled ceilings. These ceiling systems are commonly found in open offices, lobbies, conference rooms, and classrooms.
Each individual cloud panel can measure up to 4’ x 12’, and panels can be joined together to form larger, seamless elements. The panels are also available with cutouts and/or channels for lighting and HVAC integration. Edge panels are offered with finished perimeters in square and knife-edge profiles, eliminating the need for trim. Modifications to returns allow for deeper or shallower expressions. Suspension is typically achieved with threaded rods or wire. All supports are recessed, fully concealing the vertical support elements.
Clouds come with a fleece backing, achieving an acoustic rating of NRC 0.75, but adding a fiberglass or similar backing material can boost the rating to NRC 1.00.
What is the Dur-Solo ceiling system?
The Dur-Solo ceiling system consists of clouds made from perforated metal panels or expanded metal mesh, providing both aesthetic and acoustic benefits.
What materials are Dur-Solo panels made from?
Dur-Solo panels are crafted from steel, aluminum, or stainless steel, offering durability and design flexibility.
What finish options are available for Dur-Solo clouds?
Dur-Solo clouds are available in various finishes, including:
- Powder-coated
- Anodized
- Mirror-polished
- Custom digital printing for unique aesthetics
What is the maximum panel size for Dur-Solo clouds?
Each individual cloud panel can measure up to (4’ × 12’). Panels can be joined together to form larger, seamless elements.
Can Dur-Solo panels be fabricated with factory cutouts?
Yes, Dur-Solo panels can be customized with cutouts and channels for lighting, HVAC integration, fire sprinklers, or speakers, ensuring seamless coordination with building systems.
How are Dur-Solo clouds supported?
Suspension is typically achieved using threaded rods or wire. All supports are recessed, fully concealing the vertical support elements for a clean, floating appearance.
What edge profiles are available for Dur-Solo clouds?
Edge panels are offered with finished perimeters in the following profiles:
- Square-edge
- Knife-edge
What is an acoustical cloud?
Acoustical clouds are when individual acoustic panels are suspended horizontally from the ceiling and hovering in the air like a cloud. Panels that are hung vertically are often called baffles. The benefits of a cloud are that you use less material than a continuous ceiling and you may be able to suspend the material closer to the noise source in a large room. Clouds can also create the sense of a larger space than a continuous ceiling.
